Overview
Moreover, the ADRE-208-P combines high-speed analog input capability, synchronous multi-channel sampling, and rugged field portability, making it an ideal solution for condition monitoring and diagnostic analysis of turbines, compressors, generators, and rotating equipment across power, oil & gas, and industrial sectors.
Specification
| Parameter | Specification |
|---|---|
| Model | Bently Nevada ADRE-208-P |
| Function | Data Acquisition and Interface Module |
| Input Channels | 16 dynamic signal channels (simultaneous sampling) |
| Sampling Rate | Up to 51.2 kHz per channel |
| Resolution | 24-bit analog-to-digital conversion |
| Transducer Power Supply | Supports proximity probes and accelerometers |
| Communication Interfaces | USB 2.0, Ethernet (TCP/IP) |
| Signal Conditioning | Integrated filtering and gain control |
| Synchronization | Hardware and software clock synchronization |
| Power Supply | 100–240 VAC, 50/60 Hz input |
| Operating Temperature Range | 0°C to +50°C |
| Storage Temperature Range | -20°C to +70°C |
| Enclosure Type | Portable ruggedized aluminum housing |
| Dimensions | 330 mm x 280 mm x 115 mm (approx.) |
| Weight | Approx. 4.5 kg (10 lb) |
| Software Compatibility | ADRE for Windows |
| Certifications | CE, FCC, EN 61326 compliant |
FAQ
Q1: What is the main purpose of the ADRE-208-P?
A1: It captures and processes high-fidelity vibration and dynamic signals for machinery health diagnostics.
Q2: Which software works with the ADRE-208-P?
A2: It integrates seamlessly with Bently Nevada’s ADRE for Windows software.
Q3: How many input channels does it support?
A3: It supports 16 simultaneous dynamic input channels for high-speed signal acquisition.
Q4: Is it suitable for field and lab use?
A4: Yes, its portable and rugged design allows flexible use in both environments.
Q5: What kind of sensors are compatible?
A5: It supports proximity probes, accelerometers, and other vibration transducers.
