Overview
Specification
| Parameter | Specification |
|---|---|
| Model Number | 9907-827 |
| Module Type | Digital Governor / Load Sharing / Speed Control Module |
| Primary Function | Precise speed regulation and digital load sharing for turbines and generators |
| Power Supply | 24 VDC nominal |
| Power Consumption | ~15 W |
| Operating Temperature | –40°C to +85°C |
| Storage Temperature | –40°C to +85°C |
| Digital I/O | 16 configurable digital inputs, 10 configurable outputs |
| Analog I/O | 4 configurable analog inputs, 2 configurable analog outputs |
| Control Type | Digital speed and load control for turbine/generator systems |
| Communication Interface | RS‑232, RS‑485, Ethernet |
| Mounting | Rack or panel mount |
| Indicators | LEDs for alarm, status, and power |
| Regulatory Compliance | CE marked, UL recognized |
| Redundancy / Safety Features | Supports redundant speed sensing and fault-diagnostic logic |
| Typical Applications | Steam/gas turbines, power generation plants, multi-generator systems |
| Speed Control Scheme | Supports isochronous regulation and droop mode via 2301A series architecture |
FAQ
A1: It is designed for gas turbines requiring precise load sharing and speed control.
Q2: Can the module synchronize multiple turbines?
A2: Yes, it supports multi-turbine synchronization within power generation plants.
Q3: What communication protocols are supported?
A3: The module is compatible with Woodward Micronet and NetCon networks.
Q4: What is the operating temperature range?
A4: The device operates safely between –20°C and +70°C in industrial environments.
Q5: How are alarms and diagnostics handled?
A5: Configurable LEDs and communication outputs provide real-time status and fault alerts.
