Overview
The Honeywell 8C-PDODA1 51454472-175 is a Series 8 digital output module designed for seamless integration with the Honeywell C300 Controller. It delivers precise and reliable 24VDC digital outputs, supporting bussed SINK operation for industrial automation applications. This module ensures consistent performance and allows easy field isolation while maintaining high-speed response.
The 8C-PDODA1 features fast switching times and robust galvanic isolation, making it suitable for safety-critical and high-reliability systems. Its design optimizes channel density, installation efficiency, and field maintenance.
The Digital Output Bussed 24VDC has provisions for both internal and external field power excitation. As a bussed output device, all of the outputs share a common return (ground). All outputs get their power from the same source, which can be either the system power supply or an externally connected 24V power supply. When selection is from an external source, outputs can be galvanically isolated from the Series 8 power system.
Specification
| Feature | Specification |
|---|---|
| Manufacturer | Honeywell |
| Product Number | 8C-PDODA1 51454472-175 |
| Module Type | Series 8 Digital Output |
| Output Voltage | 24 VDC |
| Output Channels | 32 |
| Output Type | SINK (Open Drain) |
| Load Current | 0.1 A per channel (max) |
| Galvanic Isolation | 1000 VAC RMS System-to-Field |
| On-State Voltage | 0 VDC (0.1 A max load current) |
| Off-State Voltage | 24 VDC typical |
| Off-State Leak Current | 100 µA max |
| Turn-On/Turn-Off Time | 10 ms max |
| IOTA Model | CC-TDODA1 Non-Redundant, 9 |
| Shipping Weight | 3 Kg |
