Overview
The Honeywell 8C-PDOD51 51454475-175 is a precision digital output module designed for seamless integration with the Honeywell Experion C300 controller. This module ensures reliable 24V bussed output, supporting industrial automation systems with high accuracy and efficiency.
Engineered for Series 8 I/O systems, the 8C-PDOD51 provides bussed output channels that reduce wiring complexity while maintaining individual channel monitoring. Users can configure the module for critical output applications and observe channel-level diagnostics in real time.
The Digital Output Bussed 24VDC has provisions for both internal and external field power excitation. As a bussed output device, all of the outputs share a common return (ground). All outputs get their power from the same source, which can be either the system power supply or an externally connected 24V power supply. When selection is from an external source, outputs can be galvanically isolated from the Series 8 power system. A wiring option on the IOTA determines if outputs are referenced to the Series 8 system power or an external field power source.
Specification
| Specification | Details |
| Manufacturer | Honeywell |
| Product Number | CC-PDOD51 |
| Product Type | Series C Digital Output Module |
| Input / Output Model | CC-PDOD51 – 24V Digital Output, Field Isolated, Bussed, Coated |
| IOTA Model Numbers | CC-TDOD51, Non Redundant, 9 |
| Output Channels | 32 |
| Output Type | SINK (Open Drain) |
| Load Voltage | 30 VDC Maximum |
| Load Current | 0.1 A per channel (Max) |
| Galvanic Isolation | 1000 VAC RMS for System-to-Field isolation (user-supplied field power) |
| On-State Voltage | 0 VDC (load current @ 0.1A max) |
| Off-State Voltage | 24 V (typical) |
| Off-State Leak Current | 100 碌A (max) |
| Turn-On / Turn-Off Time | 10 ms (max) |
| Gap (Output to Field on Switchover) | None (0 ms, applies to redundancy only) |
| Shipping Weight | 3 Kg |
Manual/Datasheet PDF
8C-PDOD51 Honeywell Experion C300 24Volt Digital Output Bussed output datasheet
