Overview
This cable is compatible with MicroLogix 1000, 1100, 1200, and 1500 series controllers, making it an adaptable choice for various automation systems. In addition, it simplifies installation and setup, allowing engineers to save time while ensuring reliable performance. System integrators also rely on this cable to facilitate smooth communication during system configuration, testing, and maintenance.
Furthermore, the 1761-CBL-AP00 enhances operational efficiency by providing consistent data transfer rates and preventing communication errors. Its flexible design and compact form allow easy routing within control panels, maintaining an organized and professional setup. Therefore, OEMs and industrial facilities trust this cable for dependable and uninterrupted controller communication.
Specification
| Parameter | Specification |
|---|---|
| Part Number | 1761-CBL-AP00 |
| Cable Type | RS-232 Serial Communication |
| Connector (PC Side) | DB9 Male |
| Connector (PLC Side) | 6-pin Mini DIN |
| Cable Length | 1.8 meters (6 feet) |
| Conductor Material | High-quality copper for stable signal transmission |
| Conductor Gauge | 28 AWG |
| Shielding | Twisted pair with foil and braid for EMI protection |
| Insulation Material | PVC, flame-retardant and industrial-grade |
| Operating Temperature | 0°C to +60°C |
| Storage Temperature | -20°C to +70°C |
| Maximum Voltage | 30V DC (RS-232 standard) |
| Communication Standard | RS-232, supports standard baud rates up to 115.2 kbps |
| Supported Controllers | MicroLogix 1000, 1100, 1200, 1500 Series |
| Certifications / Compliance | CE, UL Recognized Component |
| Durability / Flexibility | Resistant to bending, abrasion, and industrial wear |
| Typical Applications | PLC programming, monitoring, troubleshooting, HMI/SCADA integration |
FAQ
A1: It works with MicroLogix 1000, 1100, 1200, and 1500 series controllers.
Q2: Can I use this cable for long-distance communication?
A2: It supports standard RS-232 distances, usually up to 15 meters, with proper extension.
Q3: Does the cable include shielding to prevent interference?
A3: Yes, it has twisted pair shielding with foil and braid for EMI protection.
Q4: Can I use it for live PLC monitoring?
A4: Yes, it fully supports real-time programming, monitoring, and troubleshooting operations.
Manual/Datasheet PDF
