Overview
Furthermore, the PanelView 1400e supports robust communication protocols, enabling efficient data transfer between the terminal and PLCs. Its compact and rugged construction allows flexible installation within control panels, ensuring both professional setup and long-term operational stability. Therefore, it remains a trusted component for OEMs, system integrators, and industrial facilities worldwide.
Specification
| Parameter | Specification |
|---|---|
| Part Number | 1400ELKC6/E |
| Product Type | PanelView 1400e Keypad Terminal |
| Display Type | Monochrome LCD |
| Display Size | 4.5 inches diagonal |
| Resolution | 240 x 128 pixels |
| Keypad | 16-button numeric and function keypad |
| Communication | RS-232, DF1 protocol, supports PLC connectivity |
| Power Supply | 24V DC |
| Operating Temperature | 0°C to +55°C |
| Storage Temperature | -20°C to +70°C |
| Mounting | Panel mount with bezel |
| Certifications / Compliance | UL, CE |
| Dimensions (H x W x D) | 152 mm x 241 mm x 58 mm |
| Weight | 1.1 kg |
| Enclosure Rating | NEMA 4 / IP65 (front panel) |
| Typical Applications | Machine control, process monitoring, HMI interface, factory automation |
FAQ
A1: It supports DF1 protocol and RS-232 communication, compatible with most MicroLogix and SLC series PLCs.Q2: Can this terminal operate in harsh industrial environments?
A2: Yes, its rugged NEMA 4/IP65 front panel protects against dust and moisture.
Q3: Does it support real-time monitoring and operator input?
A3: Absolutely. It provides precise keypad control for live process monitoring and operation.
Q4: What is the recommended mounting method?
A4: The terminal is designed for panel mounting with a secure bezel installation.
