Overview
This module also provides clear diagnostic feedback through LED indicators for each channel, enabling engineers to monitor input status and module operation effectively. By combining high-quality construction with advanced electrical specifications, the 140DAI74000 guarantees long-term reliability in demanding industrial environments.
Specification
| Feature | Specification |
|---|---|
| Manufacturer | Schneider Electric |
| Range of Product | Modicon Quantum |
| Model | 140DAO74000 |
| Module Type | VAC Discrete Output Module |
| Discrete Outputs | 16 |
| Output Voltage | 230 V AC |
| Output Current | ≤ 11.5 mA (57–63 Hz), ≤ 9.7 mA (47–53 Hz) |
| Voltage State 1 Guaranteed | 165–264 V AC (57–63 Hz), 175–264 V AC (47–53 Hz) |
| Voltage State 0 Guaranteed | 0–40 V AC |
| Output Impedance | 26.5 kΩ (57–63 Hz), 31.8 kΩ (47–53 Hz) |
| Response Time | 4.9–0.75 ms Off-On, 7.3–12.3 ms On-Off |
| Isolation Between Channels | 1780 Vrms for 1 minute |
| Isolation Between Channels/Bus | 1780 Vrms for 1 minute |
| Bus Current Requirement | 180 mA |
| Power Dissipation | ≤ 5.5 W |
| Status LEDs | 16 green outputs, 1 green bus (Active), 1 red fault (F) |
| Standards & Certifications | CE, CUL, CSA C22.2 No 142, UL 508, FM Class 1 Division 2 |
| Electrostatic Discharge | 4 kV contact, 8 kV air |
| Electromagnetic Field Resistance | 10 V/m 80–2000 MHz |
| Operating Temperature | 0–60°C |
| Storage Temperature | -40–85°C |
| Relative Humidity | 95% without condensation |
| Operating Altitude | ≤ 5000 m |
| Weight | 0.35 kg |
| Module Format | Standard |
FAQ
Q1: Is the 140DAO74000 module original and factory new?
A1: Yes, the 140DAO74000 is 100% original, factory-sealed, and ready for deployment.
Q2: How fast can it be shipped?
A2: We ship within 3 days to 2 weeks depending on order quantity using DHL or other reliable logistics.
Q3: Can it handle faults or miswiring?
A3: Yes, the module provides robust protection, including channel-to-bus isolation and external fault detection via LED.
Q4: What sensors or systems is it compatible with?
A4: It works with standard VAC industrial automation systems requiring 230 V AC discrete outputs.
Q5: What is the operational environment range?
A5: The module operates reliably from 0–60°C, with storage capability from -40–85°C and relative humidity up to 95% without condensation.
