Overview
Hardware Specifications
| Parameter | Specification |
|---|---|
| Model | AKB337-M010 |
| Base Model | AKB337 |
| Brand | Yokogawa |
| Manufacturer | Yokogawa Electric Corporation |
| Product Type | Signal Cable (FIO System Cable) |
| Cable Length | 10 m |
| Connector Type | 50-pin connectors on both ends |
| Compatible Hardware | Yokogawa FIO digital/analog I/O cards and compatible terminal blocks |
| System Compatibility | CENTUM VP, CENTUM CS 3000 |
| Insulation Resistance | Minimum 10 Mohm at specified DC test voltages |
| Operating Temp | -20 deg C to +70 deg C |
| Outer Jacket Material | Flame-retardant industrial PVC |
| Weight | Approximately 1.2 kg to 1.5 kg |
| Origin | Japan / Indonesia |
FIO Signal Transmission and Cable Routing
The AKB337-M010 provides a physical connection between compatible FIO system components. Its 50-pin connectors terminate the cable at both ends, allowing signals to pass between the designated I/O and terminal interfaces.
Furthermore, the 10 m cable length supports routing between separate control panel assemblies. The installer must verify connector compatibility and terminal assignments before connecting the cable.
The cable’s insulation resistance specification is a minimum of 10 Mohm under the specified DC test conditions. However, the supplied information does not define the test voltage or connector pin assignments.
Frequently Asked Questions
Q: What is the cable length of the Yokogawa AKB337-M010?
A: The AKB337-M010 has a specified cable length of 10 m.
Q: Which connector configuration does this cable use?
A: The cable has 50-pin connectors on both ends. Verify the mating interface and pin assignment against the applicable Yokogawa system documentation.
Q: Can the AKB337-M010 connect directly to any Yokogawa I/O module?
A: No universal compatibility is specified. Confirm that the module, terminal board, and connector configuration support the AKB337 cable assembly before installation.
Field Installation Guidelines
- Verify the AKB337-M010 model designation and connector configuration before installation.
- Confirm compatibility with the designated Yokogawa FIO I/O module and terminal board.
- Inspect both connectors for damaged contacts, contamination, or mechanical deformation.
- Route the cable through the designated control panel wiring paths. Avoid sharp bends, excessive pulling force, and mechanical compression.
- Separate signal cabling from power conductors where practical to reduce electrical interference.
- Maintain the cable’s outer jacket integrity during installation and securing.
- Confirm connector seating and mechanical retention before energizing the control system.
- Follow the applicable Yokogawa installation documentation for grounding, shielding, and pin assignment requirements.
