Woodward 5464-551 Integrating Actuator Driver Module

Overview

The Woodward 5464-551, also cataloged as the 5464-551 Integrating Actuator Driver Module, operates as a dedicated hardware component for actuator current and voltage signal execution within the Woodward NetCon 5000 control system.

Hardware Specifications

Actuator Loop Feedback Response

The Woodward 5464-551 applies actuator loop feedback response control for precise position regulation. The module receives processor commands from the NetCon 5000 platform and generates proportional electrical outputs for connected actuators.

Furthermore, the module supports closed-loop operation with LVDT or RVDT feedback devices. This configuration allows the controller to compare commanded position values with actual actuator movement and adjust output signals accordingly.

The actuator interface design supports turbine governor and mechanical control applications where signal accuracy and response characteristics affect speed, load, or valve positioning performance.

Frequently Asked Questions

Q: What type of actuators can connect to the Woodward 5464-551 module?
A: The 5464-551 interfaces with hydraulic, pneumatic, and electro-mechanical actuator systems that require controlled current or voltage drive signals.

Q: Does the 5464-551 support closed-loop actuator positioning?
A: Yes. The module supports closed-loop positioning when used with compatible LVDT or RVDT feedback sensors within the NetCon 5000 control architecture.

Q: How does the module indicate hardware status?
A: The module provides front panel LED indicators for operational status and fault identification during system diagnostics.

Field Installation Guidelines

• Install the 5464-551 module in the designated Woodward NetCon 5000 card cage slot according to system configuration requirements.
• Verify actuator wiring polarity and signal routing before applying control power.
• Use shielded cables for actuator feedback wiring when connecting LVDT or RVDT position sensors.
• Connect cable shields according to the plant grounding practice to reduce electrical interference.
• Separate actuator signal wiring from high-current power cables to minimize induced noise.
• Confirm processor communication and module status indicators after installation.
• Perform actuator calibration procedures according to the applicable Woodward control system documentation.
