Overview
The ABB TU810V1 3BSE013230R1 serves as a compact Module Termination Unit (MTU) in the S800 I/O line. It handles 16 signal terminals at 50V, and links field wiring to I/O modules and ModuleBus. It supports keying options to prevent module mismatch, mounted on DIN-rail for flexible installation.
Specification
| Parameter | Value |
|---|---|
| Manufacturer | ABB |
| Model / Part Number | TU810V1 3BSE013230R1 |
| Product Type | Module Termination Unit (MTU), Compact |
| Signal Terminals | 16 (2 × 8 signal terminals) |
| Nominal Voltage | 50V DC |
| Channels (I/O) | Field signals; Channel Type: N/A (not active I/O module) |
| Mounting | DIN-rail; allowed horizontal and vertical mounting |
| Temperature, Operating | 0 to +55 °C (horizontal), +40 °C (vertical) |
| Storage Temperature | -40 to +70 °C |
| Wire Size (Solid) | 0.2 – 4 mm² |
| Wire Size (Stranded) | 0.2 – 2.5 mm² |
| Voltage for Dielectric Test | 500 V AC |
| Weight | ~0.2 kg (~0.44 lbs) |
| Dimensions (W × H × D) | Width ≈ 64 mm, Height ≈ 170 mm, Depth ≈ 58.5 mm |
| Certifications / Compliance | RoHS, WEEE Cat 5, CE, EN/UL 61010 safety, Marine & ATEX/Zone-2 standards |
