Overview
The Honeywell TC-FPDXX2 is an uncoated Series-A power supply module designed for Honeywell C200 / C200E control systems. It delivers regulated 24 VDC and various backplane voltages to power controller racks. With high input flexibility and solid current ratings, this module supports demanding industrial automation environments.
Specification
| Specification | Details |
|---|
| Manufacturer | Honeywell |
| Model Number | TC-FPDXX2 |
| Module Type | Series-A Power Supply Module |
| Series | Uncoated (Series-A) |
| Input Voltage Range | 19.2-32 VDC |
| Input Power | 100 W |
| Maximum Inrush Current | 30 A |
| Total Output Power @ 60 °C | 70 W |
| Backplane Output Currents | 1.5 A @ 1.2 V; 4 A @ 3.3 V; 10 A @ 5.1 V; 2.8 A @ 24 V |
| Fuse Protection | Non-replaceable soldered fuse |
| Wiring | #14 AWG (≈ 1.4 mm) |
| Dimensions (L × D × H) | 11.2 × 14.5 × 14.0 cm (≈ 4.41 × 5.71 × 5.51 in) |
| Weight | ~ 1.1 kg |
| Mounting Location & Slot Impact | Left side of chassis; does not consume a slot |
| Operating Temperature Range | 0 °C to +60 °C |
