Overview
Specification
| Parameter | Specification |
|---|---|
| Manufacturer | ALSTOM / Converteam |
| Model Number | PIB101C / PIB-101C |
| Module Type | Analog Input/Output PIB Module |
| Signal Type | Analog (Voltage / Current) |
| Input Channels | 8 differential analog input channels (configurable) |
| Output Channels | 8 analog output channels |
| Input Range | 0–10 VDC or 4–20 mA (software selectable) |
| Output Range | 0–10 VDC or 4–20 mA |
| Resolution | 12-bit to 16-bit (depending on system configuration) |
| Isolation | Channel-to-channel and system-to-ground isolation |
| Communication Interface | Compatible with ALSTOM and Converteam control networks |
| Operating Voltage | 24 VDC nominal |
| Power Consumption | <10 W |
| Operating Temperature | 0°C to +60°C |
| Storage Temperature | -40°C to +85°C |
| Mounting Type | Rack-mounted |
| Dimensions (Approx.) | 200 mm × 100 mm × 30 mm |
| Weight | 0.45 kg |
| Certifications | CE, IEC compliant |
| Maintenance | Field-replaceable, service-friendly module design |
FAQ
The module supports both voltage and current analog signals, such as 0–10 VDC and 4–20 mA ranges.
Q2: Is the PIB101C compatible with existing Converteam control systems?
Yes. It integrates seamlessly with Converteam and ALSTOM automation architectures.
Q3: Can this module operate in high-noise environments?
Absolutely. It features excellent noise rejection and galvanic isolation to ensure stable signal performance.
Q4: How does maintenance work for the PIB101C?
The module is designed for quick serviceability. Engineers can replace it easily in the field without full system disassembly.
Q5: What industries use this module most frequently?
Common applications include power generation, oil and gas processing, and industrial automation systems.
