Overview
Specification
| Parameter | Specification |
|---|---|
| Manufacturer | Basler Electric |
| Model | DECS-100-B15 |
| Product Type | Digital Excitation Control / Voltage Regulator |
| Excitation Control Range | 15 A nominal (B15 model) |
| Control Modes | Automatic Voltage Regulation (AVR), Manual, VAR/PF |
| Input Power Supply | 85 to 264 VAC, 50/60 Hz |
| Field Output Voltage | 0 to 125 VDC continuous |
| Field Current Output | 0 to 15 A continuous, 20 A for 10 s |
| Voltage Sensing | 63.5 to 480 VAC (phase-to-phase or phase-to-neutral) |
| Regulation Accuracy | ±0.25% of nominal sensing voltage |
| Communication Interface | RS-485 Modbus RTU |
| Setpoint Adjustments | Local potentiometer, remote input, or digital command |
| Protective Functions | Overexcitation, Underexcitation, Overvoltage, Undervoltage, Loss of sensing |
| Operating Temperature | -40°C to +70°C |
| Storage Temperature | -55°C to +85°C |
| Cooling Method | Natural convection |
| Mounting Type | Panel-mounted |
| Dimensions (Approx.) | 267 mm × 165 mm × 64 mm |
| Weight | 1.8 kg |
| Compliance | UL, CSA, and CE certified |
FAQ
The B15 variant provides up to 15 A of field current output, making it ideal for medium to large generator systems.
Q2: Can it be used for both 50 Hz and 60 Hz systems?
Yes. The DECS-100-B15 automatically detects and adapts to either frequency.
Q3: Does it support communication with SCADA or remote systems?
Absolutely. It supports Modbus RTU communication through an RS-485 interface.
Q4: What happens if voltage sensing is lost?
The unit includes built-in loss-of-sensing protection, which activates field excitation shutdown to prevent damage.
Q5: How often does it require maintenance?
Routine maintenance is minimal—periodic inspection and firmware checks ensure optimal performance over years of operation.
