Overview
Specification
| Parameter | Specification |
|---|---|
| Manufacturer | ALSTOM / Converteam |
| Part Number | PIB100G |
| Product Type | Power Interface Board |
| Primary Function | Signal and power interface between control and drive systems |
| Power Supply Voltage | 24 VDC nominal |
| Input Signal Type | Analog and digital control inputs |
| Output Signal Type | Relay and logic-level outputs |
| Signal Isolation | Optically isolated input/output channels |
| Communication Interface | Parallel signal connection via edge connector |
| Number of Channels | 8 to 16 configurable I/O channels (model dependent) |
| Response Time | < 5 ms |
| Power Consumption | < 10 W typical |
| Operating Temperature | 0°C to +60°C (32°F to 140°F) |
| Storage Temperature | -40°C to +85°C (-40°F to 185°F) |
| Humidity | 5% to 95% non-condensing |
| Mounting Type | Rack or chassis-mounted |
| PCB Dimensions | Approx. 180 × 120 mm |
| Weight | Approx. 0.6 kg (1.3 lb) |
| Cooling Method | Natural convection |
| Insulation Resistance | >100 MΩ at 500 VDC |
| Dielectric Strength | 1500 VAC for 1 minute |
| Compliance | CE, IEC, and industrial safety standards |
FAQ
It serves as a power and signal interface between control units and power modules in industrial automation systems.
Q2: Can the PIB100G be used in non-ALSTOM systems?
Yes, it can integrate with compatible third-party control hardware, provided electrical characteristics match.
Q3: What environments are suitable for operation?
The board operates effectively in standard industrial environments with ambient temperatures up to 60°C.
Q4: How often should the board be serviced?
Routine maintenance every 12 months is recommended to ensure connector integrity and thermal stability.
