Overview
Specification
| Parameter | Description |
|---|---|
| CPU Type | High-performance CPU module for CENTUM VP FCS |
| Processor Performance | Fast deterministic execution for large and complex logic sequences |
| Memory Architecture | Dedicated program memory; protected runtime memory for system variables |
| Control Strategy Capacity | Supports extensive control loops, advanced logic blocks, and redundancy configurations |
| System Platform | Yokogawa CENTUM VP Field Control Station (FCS) |
| Communication Bus | High-reliability FCS control bus for stable real-time data exchange |
| Redundancy Support | Compatible with redundant FCS configurations and high-availability architectures |
| Diagnostics | Continuous internal health monitoring, watchdog functions, and error reporting |
| Power Requirement | Low-consumption module powered by standard FCS backplane supply |
| Operating Temperature | 0°C to 55°C suitable for controlled industrial environments |
| Storage Temperature | -20°C to 70°C for long-term storage and spare-part management |
| Humidity | 5%–95% RH non-condensing |
| EMC Protection | Industrial noise immunity ensuring stable performance in harsh electrical environments |
| Vibration Resistance | Designed for cabinet-mounted systems with limited vibration exposure |
| Cooling Method | Passive cooling with no moving components |
| Installation Type | Plug-in module for FCS system racks |
| Typical Integration | Process control, sequence logic, advanced control blocks, and system coordination |
| Compliance | CE and industrial automation safety standards |
FAQ
A1: It operates within Yokogawa CENTUM VP FCS architectures and integrates seamlessly with compatible I/O subsystems.
Q2: Does the module support redundant configurations?
A2: Yes, it works with Yokogawa redundant FCS designs to improve plant availability.
Q3: Can it handle complex control logic?
A3: Yes, the CPU supports large-scale strategies with advanced control blocks and reliable execution speed.
Q4: What industries typically use this module?
A4: It is commonly used in refining, petrochemicals, power generation, gas processing, and chemical manufacturing.
Q5: Does the module require frequent maintenance?
A5: No, routine checks and occasional firmware updates usually maintain long-term operational stability.
