Overview
The Honeywell MC-TDOY23 80366189-175 is a high-performance Digital Output Relay Module designed for industrial automation applications. It offers 16 independent Form C (SPDT) relay outputs, each capable of handling up to 10A, making it ideal for controlling high-current and high-voltage loads in process control systems.
Specification
| Specification | Details |
|---|
| Manufacturer | Honeywell |
| Model Number | MC-TDOY23 80366189-175 |
| Module Type | Digital Output Relay Module |
| Relay Type | Form C (SPDT) |
| Number of Outputs | 16 |
| Input Voltage Range | 12–24 VDC |
| Output Voltage Range | 5–250 V AC/DC |
| Maximum Current per Output | 10A |
| Response Time | < 5 milliseconds |
| Operating Temperature | –40°C to +85°C |
| Dimensions (L × W × H) | 12 × 8 × 6 inches |
| Weight | 2 pounds (approx. 0.9 kg) |
| Mounting | Field Terminal Assembly (FTA) |
| Safety Features | Optical isolation, LED status indicators |
| Certifications | UL, CSA |
