Overview
Specification
| Parameter | Details |
|---|---|
| Model Number | KJ3241X1-BA1 |
| Card Type | Redundant Serial Interface Card |
| Compatibility | Emerson DeltaV Controller Systems |
| Interface | RS-232 / RS-485 serial communication |
| Redundancy | Dual-card redundancy for continuous operation |
| Power Requirements | 5 VDC nominal, low power consumption |
| Operating Temperature | 0°C to 55°C (32°F to 131°F) |
| Storage Temperature | -40°C to 70°C (-40°F to 158°F) |
| Mounting | DeltaV rack installation |
| Communication Speed | Up to 115.2 kbps depending on network configuration |
| LED Indicators | Status, fault, and communication activity indicators |
| Agency Approvals | CE, UL, and other relevant industrial certifications |
| Dimensions | Standard DeltaV interface card size for rack installation |
| Applications | Process control, monitoring, and redundant industrial communication |
FAQ
A1: It is compatible with Emerson DeltaV controller systems and their associated racks.
Q2: How does redundancy work on this interface card?
A2: Two cards operate in parallel, and if one fails, the second maintains uninterrupted communication.
Q3: What type of serial communication does it support?
A3: The card supports RS-232 and RS-485 serial communication interfaces.
Q4: What is the maximum communication speed?
A4: It supports up to 115.2 kbps, depending on network configuration and device compatibility.
Q5: What environmental conditions can the card operate in?
A5: It operates reliably between 0°C and 55°C and tolerates storage temperatures from -40°C to 70°C.
Q6: Does the card require frequent maintenance?
A6: No, its industrial-grade design minimizes maintenance, but routine inspection of connections is recommended.
