Overview
It supports industry-standard analog inputs while enabling HART digital communication on the same wiring.
Moreover, the module integrates seamlessly into DeltaV Series 2 architectures, reducing engineering effort during system expansion.
Control engineers use this module to maintain accurate measurement visibility across demanding industrial operations.Designed for continuous plant operation, the module ensures stable performance in electrically noisy environments.
In addition, Emerson manufacturing standards provide long-term reliability and consistent signal integrity.
Specification
| Parameter | Description |
|---|---|
| Product Type | Analog Input Module with HART |
| Manufacturer | Emerson |
| System Platform | DeltaV Distributed Control System |
| Model Number | KJ3222X1-BA1 |
| Order Numbers | 12P2532X062 / 12P2532X142 |
| Series | DeltaV Series 2 |
| Input Signal Type | Analog with HART communication |
| Supported Signals | Typical 4–20 mA analog inputs |
| HART Support | HART pass-through communication |
| Channel Configuration | Multi-channel analog input |
| Isolation | Industrial-grade channel isolation |
| Mounting Type | DeltaV I/O carrier mounting |
| System Compatibility | DeltaV Series 2 controllers |
| Operating Environment | Industrial process control environments |
| Duty Rating | Continuous industrial operation |
| Compliance | Designed to meet DeltaV system specifications |
FAQ
A1: It acquires analog input signals while supporting HART communication for smart field devices.Q2: Does this module support standard 4–20 mA transmitters?
A2: Yes, it supports typical 4–20 mA analog input signals used in industrial instrumentation.
Q3: Can HART communication operate simultaneously with analog signals?
A3: Yes, HART data transmits digitally over the same analog signal wiring.
Q4: Is this module compatible with all DeltaV systems?
A4: It is designed specifically for DeltaV Series 2 I/O architectures.
Q5: Does the module require regular calibration or maintenance?
A5: No routine calibration is required beyond standard DeltaV system maintenance practices.
