Overview
Specifically, it delivers controlled 24 VDC outputs to field devices, therefore ensuring predictable actuator and solenoid operation.
Moreover, the 32-channel density optimizes cabinet space utilization while maintaining clear channel-level diagnostics.
Engineers select this module when dependable output control and tight DeltaV system integration remain critical project requirements.
Specification
| Parameter | Specification |
|---|---|
| Product Model | KJ3204X1-BA1 |
| Product Type | Discrete Output Module, High-Side |
| Manufacturer | Emerson Automation Solutions |
| DeltaV Series | Series 2 |
| Number of Output Channels | 32 discrete output channels |
| Output Type | 24 VDC high-side switching |
| Rated Output Voltage | 24 VDC nominal |
| Maximum Output Current | Typical industrial load rating per channel |
| Output Protection | Short-circuit and overload protection |
| Channel Isolation | Grouped isolation to system |
| Field Power Requirement | External 24 VDC supply |
| System Compatibility | Emerson DeltaV Distributed Control System |
| Mounting Location | DeltaV I/O carrier |
| Primary Function | Discrete control of field devices |
| Operating Environment | Industrial control cabinet conditions |
FAQ
A1: It provides 32 channels of high-side 24 VDC discrete output control within DeltaV systems.Q2: What does high-side output mean in this module?
A2: High-side outputs supply positive voltage to the load while the return path connects to common.
Q3: Is this module compatible with all DeltaV systems?
A3: It is designed for Emerson DeltaV systems using compatible Series 2 I/O carriers.
Q4: Can the module drive inductive loads such as solenoids?
A4: Yes, it is commonly used for solenoids, relays, and similar industrial field devices.
Q5: Does the module provide diagnostic information?
A5: Yes, DeltaV diagnostics allow monitoring of channel status and fault conditions.
