Overview
It delivers 24 VDC high-side switching, therefore enabling safe and stable actuation of field devices.
Moreover, the module integrates seamlessly into DeltaV Series 2 architectures with minimal configuration effort.
Control engineers rely on this output card to ensure predictable switching performance under continuous industrial operation.Designed for long-term use, the module supports robust electrical performance in electrically noisy plant environments.
In addition, Emerson manufacturing standards ensure consistent quality across extended system lifecycles.
Specification
| Parameter | Description |
|---|---|
| Product Type | Digital Output Module |
| Manufacturer | Emerson |
| System Platform | DeltaV Distributed Control System |
| Model Number | KJ3202X1-BA1 |
| Series | DeltaV Series 2 |
| Output Type | High-side digital output |
| Output Voltage | 24 VDC |
| Channel Configuration | Multi-channel digital output |
| Switching Function | Sources voltage to field devices |
| Electrical Design | Industrial-grade output protection |
| Mounting Type | DeltaV I/O carrier mounting |
| System Compatibility | DeltaV Series 2 controllers and I/O |
| Operating Environment | Industrial process control environments |
| Reliability Rating | Continuous-duty industrial operation |
| Compliance | Designed to meet DeltaV system standards |
FAQ
A1: It provides 24 VDC high-side digital output signals to control industrial field devices.Q2: What does high-side output mean in this module?
A2: It sources voltage to the load, simplifying wiring and improving output safety.
Q3: Is this module compatible with all DeltaV systems?
A3: It is designed specifically for DeltaV Series 2 I/O architectures.
Q4: Can this module operate continuously in industrial environments?
A4: Yes, it supports continuous-duty operation in demanding process control applications.
Q5: Does the module require routine maintenance?
A5: No routine maintenance is required beyond standard DeltaV system inspections.
