Overview
In addition, the IS200TDBSH2A actively supports high-speed switching and secure terminal connections, allowing engineers to implement highly efficient signal routing. Consequently, its modular architecture simplifies system upgrades while providing clear diagnostics during maintenance. For instance, operators can quickly identify and address potential issues, making it ideal for critical control applications where reliability and continuous operation are essential.
Specification
| Parameter | Specification | Notes |
|---|---|---|
| Model | IS200TDBSH2A（IS230TNDSH2A) | GE Fanuc discrete I/O module |
| Module Type | Discrete Input/Output | Manages digital signals for turbine/process control |
| Function | Signal interface for field devices | Ensures reliable input/output switching |
| Compatible Systems | Mark V, Mark VIe | Integrates with legacy and modern control architectures |
| Input Channels | 16 discrete inputs | Individually isolated for signal integrity |
| Output Channels | 16 discrete outputs | Supports safe switching of actuators and relays |
| Terminal Type | Screw terminals | Secure connections for field wiring |
| Switching Capacity | 1 A per point | Standard industrial load compatibility |
| Signal Type | Digital (On/Off) | Supports common industrial sensors and devices |
| Isolation | Channel-to-channel & channel-to-ground | Enhances operational safety |
| Operating Voltage | 24 VDC nominal | Standard industrial control voltage |
| Max Operating Temperature | 70°C | Reliable operation in typical industrial environments |
| Storage Temperature | -40°C to 85°C | Safe for storage and transportation |
| Relative Humidity | 5–95% non-condensing | Maintains functionality in humid conditions |
| Mounting | DIN rail or backplane | Flexible integration in panels or racks |
| Dimensions | Approx. 150 mm x 100 mm x 35 mm | Compact form factor |
| Weight | Approx. 0.55 kg | Lightweight and easy to handle |
| Compliance | CE, UL | Meets industrial safety and quality standards |
FAQ
A1: It is compatible with Mark V and Mark VIe turbine and process control systems.
Q2: How many discrete input and output channels are included?
A2: The module provides 16 discrete input channels and 16 discrete output channels.
Q3: What is the nominal operating voltage for this module?
A3: The IS200TDBSH2A operates at a standard 24 VDC industrial control voltage.
Q4: Can the module withstand high temperatures?
A4: Yes, it operates reliably up to 70°C and stores safely between -40°C and 85°C.
Q5: How is the module installed in control systems?
A5: It supports DIN rail or backplane mounting for flexible panel or rack installation.
Q6: Does it provide channel isolation?
A6: Yes, channel-to-channel and channel-to-ground isolation ensures safe operation and signal integrity.
