Overview
In addition, the HIEE205012R0001 seamlessly integrates with ABB UNITROL series controllers, supporting efficient generator excitation and voltage regulation. Its compact form factor, combined with advanced analog circuitry, enhances reliability and simplifies installation in both retrofit and new system configurations.
Specification
| Parameter | Specification |
|---|---|
| Part Number | HIEE205012R0001 |
| Model | UNC 4672A V.1 |
| Product Type | Analog Measuring Card |
| Series | UNITROL |
| Function | Analog measurement and signal conditioning |
| Input Signal Types | Voltage and current analog inputs |
| Output Signal | Conditioned analog signals for control processing |
| Supply Voltage | 24 VDC nominal |
| Accuracy | ±0.2% of full scale |
| Operating Temperature | 0°C to +55°C |
| Storage Temperature | -25°C to +70°C |
| Mounting Type | Plug-in module |
| Isolation | Galvanically isolated input and output channels |
| Dimensions | Compact standard UNITROL card size |
| Certifications | CE, IEC, and ISO compliance |
| Maintenance | Low-maintenance, field-replaceable module |
FAQ
Q1: What is the function of the ABB HIEE205012R0001 module?
It measures analog electrical parameters and converts them into precise signals for the UNITROL excitation system.
Q2: Is the module compatible with all UNITROL versions?
Yes, it integrates smoothly with the UNITROL 1000 and 6000 series, as well as older ABB excitation systems.
Q3: Can it operate under high-temperature conditions?
Absolutely. The module performs reliably up to +55°C with consistent accuracy and thermal stability.
Q4: How often does it require maintenance?
Minimal maintenance is required. ABB recommends periodic functional tests during scheduled system servicing.
