Overview
The GE IS210MACCH2AEF is identified in the supplied material as a communication and control module associated with industrial turbine management systems. The source description lists Ethernet and serial communication interfaces, processor and memory specifications, and support for several industrial communication protocols. However, the listed hardware configuration and performance ratings require model-specific verification before they can be treated as confirmed specifications.
Functional Description
A communication and control module handles data exchange between control-system components and connected devices. In a turbine control environment, such functions may support controller-to-I/O communication and the transfer of operating data. The exact role of the IS210MACCH2AEF, including its network architecture and supported interfaces, should be confirmed against the module nameplate and applicable technical documentation.
Technical Specifications
| Parameter | Specification |
|---|---|
| Model | IS210MACCH2AEF |
| Brand | GE |
| Product Type | Communication and Control Module |
| Reported System Platform | Mark VI Speedtronic |
| Power Input | 24 VDC +/- 10% |
| Maximum Input Current | 5 A |
| Reported Power Rating | 120 W |
| Processor | Intel Core i5-4570TE, 2.7 GHz, quad-core |
| Memory | 8 GB DDR4 RAM |
| Ethernet Interfaces | 4 x Gigabit Ethernet, 10/100/1000 Mbps |
| Serial Interfaces | 2 x RS-485/RS-422 |
| Serial Communication Speed | 50 to 921600 bps |
| Time Synchronization | IEEE 1588 PTP |
| Reported Protocols | Modbus TCP/IP, DNP3, IEC 61850 |
| Storage | 128 GB SSD |
| Operating Temperature | -40 to +70 deg C |
| Reported Shock and Vibration Standard | MIL-STD-810G |
| Dimensions | 320 x 200 x 50 mm |
| Mounting | 19-inch rack installation |
Configuration Verification
The supplied specifications describe a computer-class controller with an Intel processor, DDR4 memory, SSD storage, multiple Ethernet ports, and serial interfaces. These details should not be treated as confirmed characteristics of this GE model without matching technical documentation.
Before selecting the module, verify the complete part number, hardware revision, power supply requirements, communication interfaces, and mechanical dimensions. These checks help distinguish the required hardware from similarly numbered modules with different functions or configurations.
Frequently Asked Questions
Q: Is the IS210MACCH2AEF compatible with the GE Mark VI Speedtronic system?
A: The supplied description associates the model with Mark VI Speedtronic, but exact compatibility has not been independently verified. Confirm the full part number and hardware revision against the installed system documentation before ordering.
Q: Does this module support Modbus TCP/IP, DNP3, and IEC 61850?
A: These protocols appear in the supplied specifications, but support for all three has not been confirmed for this exact model. Verify the available interfaces and protocol implementation before planning a system connection.
Q: Can the module operate from a 24 VDC supply?
A: The supplied data lists 24 VDC +/- 10%. Confirm the module’s actual input rating and current requirements from its nameplate or applicable hardware documentation before applying power.
