Overview
Specification
| Parameter | Specification |
|---|---|
| Model | GCU08CB-130 |
| Mitsubishi Part Number | 80173-109-01-3 |
| Module Type | Thyristor Inverter Power Board |
| Input Voltage | AC 200–240 V ±10% |
| Input Frequency | 50/60 Hz ±5% |
| Output Voltage | Configurable based on inverter settings (AC 0–230 V typical) |
| Output Current | Up to 30 A continuous (dependent on connected load) |
| Switching Device | Thyristor (SCR) technology for high-speed, precise control |
| Control Interface | Compatible with Mitsubishi inverter CPU and I/O modules |
| Cooling Method | Forced air cooling with integrated heat sinks |
| Operating Temperature | 0°C to 50°C |
| Extended Operating Temperature | –20°C to 70°C (optional, depending on enclosure and airflow) |
| Storage Temperature | –20°C to 70°C |
| Relative Humidity (Operation) | 5–95% RH (non-condensing) |
| Protection Class | IP20 standard (suitable for enclosed industrial panels) |
| Vibration Resistance | 0.15 mm P-P (5–58 Hz), 1 G (58–150 Hz) |
| Shock Resistance | 15 G, 11 ms (XYZ directions, power-off condition) |
| Altitude | Up to 2000 m above sea level |
| EMC / Noise Immunity | Electric field ≤3 V/m (26 MHz–1 GHz), Magnetic field ≤30 A/m AC, ≤400 A/m DC |
| Electrostatic Discharge | 4 kV contact, 8 kV air discharge |
| Mounting | Panel or rack mount compatible |
| Dimensions | Approx. 200 mm × 150 mm × 60 mm (depending on specific production batch) |
| Weight | Approx. 1.2 kg |
| Compliance / Standards | ANSI/ISA S71.04 (G2 standard, G3 optional), CE marking for industrial equipment |
FAQ
A1: It provides precise power conversion for Mitsubishi inverter systems, optimizing motor control.Q2: Can it operate in high-temperature industrial environments?
A2: Yes, it supports operating temperatures from 0°C to 50°C with proper ventilation.
Q3: Is this module compatible with other Mitsubishi inverters?
A3: Yes, it integrates seamlessly with compatible Mitsubishi inverter models.
Q4: What type of cooling does the board require?
A4: Forced air cooling is recommended to maintain optimal operating conditions.
Q5: Does it include protective features for industrial use?
A5: Yes, it has advanced fault protection and robust thermal management for durability.
Q6: How should it be mounted in an industrial setup?
A6: It is compatible with panel or rack mounting, enabling flexible system integration.
