Overview
The Honeywell FC-TDOL-0724P V1.0, identified by the base model FC-TDOL-0724P, is described in the supplied information as an industrial control and interface module. The available data does not establish its exact signal type, channel configuration, or system compatibility. Confirm the module’s electrical interface and hardware designation against the manufacturer’s documentation before assigning it to a specific control function.
Hardware Specifications
| Parameter | Specification |
|---|---|
| Model | FC-TDOL-0724P V1.0 |
| Brand | Honeywell |
| Module Type | Industrial Control / Interface Module |
| Origin | Not specified |
| Operating Voltage | 24 VDC, reported typical value |
| Power Consumption | Approx. 250-275 mA reported |
| Operating Temp | 0 to 60 deg C, reported typical range |
| Dimensions | Approx. 320 x 170 x 140 mm, reported |
| Weight | Approx. 0.62-0.7 kg, reported |
| Mounting Type | Rack or DIN rail mounting reported |
| Certifications | CE, UL, and TUV reported |
| Version | V1.0 |
Process Control Interface Considerations
For Honeywell process-control hardware, electrical compatibility depends on the module’s documented interface, system architecture, and terminal assignment. The supplied information does not confirm whether FC-TDOL-0724P supports 4-20 mA HART, FOUNDATION Fieldbus, Profibus PA, or channel-to-channel isolation. These features must not be assumed from the manufacturer name alone.
Before integration, verify the module’s hardware classification, supported signal types, power requirements, and compatibility with the target controller or I/O subsystem.
Frequently Asked Questions
Q: Can FC-TDOL-0724P V1.0 operate from a 24 VDC supply?
A: The supplied specifications report 24 VDC as a typical operating voltage. Confirm the permitted input-voltage range, polarity, and current requirements using the applicable hardware documentation before energizing the module.
Q: Does FC-TDOL-0724P support hot-swapping?
A: Hot-swap capability is not established by the supplied information. Check the system installation manual for power-isolation requirements and restrictions on removing or inserting the module during operation.
Q: Is FC-TDOL-0724P compatible with Honeywell Safety Manager or Experion systems?
A: Compatibility with either platform has not been verified. Confirm the module’s official product designation, supported chassis or carrier, and controller compatibility before installation.
Field Installation Guidelines
- Verify the complete model number and V1.0 revision against the equipment documentation.
- Confirm the specified supply voltage, polarity, grounding arrangement, and current capacity before connecting power.
- Use the manufacturer’s terminal diagram to identify signal connections. Do not infer terminal assignments from the model number.
- Route signal wiring separately from high-voltage and high-current conductors where practical to reduce electrical interference.
- Terminate cable shields according to the system grounding design and manufacturer’s instructions.
- Confirm the permitted mounting method, enclosure requirements, and ambient temperature limits before installation.
- Isolate power before wiring or removing the module unless the manufacturer’s documentation explicitly permits live replacement.
