Overview
This module enhances system flexibility while minimizing installation space, making it an ideal choice for modern automation architectures that require both performance and efficiency.
Specification
| Category | Specification |
|---|---|
| Range of product | Modicon X80 automation platform |
| Product type | Discrete input module |
| Input channels | 16 |
| Input type | Sink logic |
| Rated input voltage | 24 VDC |
| Input voltage limits | 19–30 VDC |
| Threshold voltage | State 1 ≥ 11 V, State 0 ≤ 5 V |
| Input current | 2.5 mA per channel |
| Response time | ≤ 4 ms |
| Isolation | 1500 V RMS (channel-to-bus) |
| Bus current requirement | 40 mA |
| Local signaling | 16 green LEDs (input status) |
| Connection | 20-way removable terminal block |
| Module format | Standard |
| Dimensions (W × H × D) | 32 × 99 × 86 mm |
| Net weight | 0.12 kg |
| Certifications | CE, UL, CSA, FM Class 1 Div 2 |
| Operating temperature | 0…60 °C |
| Storage temperature | -40…85 °C |
| Relative humidity | 95% without condensation |
| Operating altitude | ≤ 2000 m |
FAQ
Yes, we only supply new, original, and factory-sealed Schneider modules.
Q2: Do you have stock available?
Yes, we keep stock, and shipment typically takes 3 days to 2 weeks, depending on order size.
Q3: Which shipping methods are supported?
We usually ship via DHL, FedEx, or UPS, ensuring fast and reliable delivery.
Q4: What is your return policy?
If there are any quality issues, you can request a return within 30 days of delivery.
Q5: How much current does the BMXDDI1602 require from the bus?
The module requires 40 mA bus current during operation.
Q6: What is the weight of the module?
The unit is lightweight at only 0.12 kg, making it easy to handle and install.
