Overview
Hardware Specifications
| Parameter | Specification |
|---|---|
| Model | 3500/25 |
| Part Number | 125792-01 |
| Brand | Bently Nevada |
| Product Type | Enhanced Keyphasor Module |
| System | 3500 Machinery Protection System |
| Input Channels | 2 |
| Compatible Sensor Types | Proximity probes, magnetic pickups |
| Frequency Range | DC to 20 kHz, subject to signal configuration |
| Power Consumption | 3.2 W typical |
Operating Function
The Keyphasor signal identifies a reference position on a rotating shaft. The module processes incoming pulses and supplies timing references to compatible monitoring modules. These references help the 3500 system calculate shaft speed and phase-related parameters.
The module supports two input channels. The overall number of Keyphasor signals depends on the rack configuration and the number of installed modules.
Replacement Considerations
Before replacing the 125792-01, check the installed module, I/O configuration, termination arrangement, and required signal-processing functions. Do not assume that another module is compatible based on its model number alone.
Frequently Asked Questions
Q: What is the purpose of the 3500/25 125792-01?
A: It processes shaft reference signals for rotational speed and phase-related monitoring in a compatible 3500 system.
Q: How many input channels does it provide?
A: It provides two Keyphasor input channels.
Q: Are the 5-24 VDC input range and 16-bit resolution confirmed?
A: The supplied information does not establish these values for the complete 125792-01 part number. Verify them against the applicable manufacturer documentation before using them for engineering or purchasing decisions.
