Overview
Specification
| Specification | Value |
|---|---|
| Analog Channels | 12 or 24 (1 or 2 A6510 modules) |
| Tachometer Channels | 2 or 4 |
| Sampling Rate | Up to 102.4 kS/s |
| Frequency Range | DC to 40 kHz |
| ADC Resolution | 24-bit |
| Dynamic Range | 100 dB |
| Ethernet Ports | 4 × 100Base-T |
| Relay Channels | 2 or 4 (SPDT 24V @ 0.5A) |
| Memory Capacity | 32 MB SDRAM, 32 MB Flash |
| Conformal Coating | IPC-A-610E |
FAQ
A: Yes, all Emerson A6560 modules we supply are guaranteed brand new and original.Q: What is the difference between A6560 and A6560-T?
A: The A6560-T includes all the features of the A6560, with the addition of onboard transient monitoring capabilities for detailed analysis of turbomachinery.Q: How many A6510 modules can be supported by the A6560?
A: Each A6560 processor can support up to two A6510 signal input modules.
Q: What is the maximum sampling rate of the A6560 processor?
A: The A6560 processor supports a maximum sampling rate of up to 102.4 kS/s.
Q: Does the A6560 support Modbus communication?
A: Yes, the A6560 processor card includes optional Modbus TCP/Ethernet output for integration with control systems.
