Overview
The Honeywell 8C-PAOHA1 51454469-275 is an advanced analog output module designed for seamless integration with the Honeywell C300 Controller. It delivers precise control and ensures reliable performance for industrial automation systems.
This module provides high-level constant current to actuators and recording or indicating devices. It supports HART communication, enabling advanced diagnostics and configuration capabilities.This Series 8 IO function can detect and annunciate open field wire with a Channel Soft Failure indication.
Specification
| Parameter | Specification | ||
| Input/Output Module | 8C-PAOHA1-Analog Output with HART,Coated | ||
| IOTA Modules | 8C-TAOXA1 | Non-Redundant,Coated | 6″ |
| 8C-TAOXB1 | Redundant,Coated | 12″ | |
| Output Type | 4-20 mA | ||
| Output Channels | 16 | ||
| Output Ripple | <100 mV peak-to-peak at power line freq,across 250 Ω load | ||
| Output Temperature Drift | 0.005%of Full Scale/℃ | ||
| Output Current Linearity | ±0.05%of Full Scale nominal | ||
| Load Resistance (24V supply=22 VDC through 28VDC) | 50-800Ω | ||
| Voltage Rating | 24VDC | ||
| Module current rating | 205 mA | ||
| Resolution | ±0.05%of Full Scale | ||
| Calibrated Accuracy | ±0.2%of FullScale(250C)including linearity | ||
| Directly Settable Output Current Range | 2.9 mA to 21.1 mA | ||
| Maximum Output Compliant Voltage (24 V supply=22 VDC through 28VDC) | 16V | ||
| Maximum Open Circuit Voltage | 22V | ||
| Response Time(DAC input code to output) | Settles to within 1%of final value within 80 ms | ||
| Gap(0mA)of Output to Field on Switchover | 10 ms maximum(applies to Redundancy only) | ||
| Module Removal and Insertion Under Power | Supported | ||
Manual/Datasheet PDF
8C-PAOHA1 51454469-275 Honeywell C300 Analog Output with HART (Copy) datasheet
