Overview
Specification
| Parameter | Details |
|---|---|
| Model Number | 6ES7322-1BH01-0AA0 |
| Manufacturer | Siemens |
| Series | SIMATIC S7-300 / SM 322 |
| Product Type | Digital Output Module |
| Output Channels | 16 |
| Output Type | Relay / 24V DC Switching |
| Nominal Voltage | 24 V DC |
| Output Current | 0.5 A per channel |
| Switching Capability | Up to 10W per channel |
| Isolation | Optically isolated outputs for reliable operation |
| Power Supply Voltage | 24 V DC |
| Power Consumption | Approx. 2.5 W |
| Module Current Draw (from backplane) | 70 mA |
| Dimensions (W x H x D) | 40 mm × 125 mm × 120 mm |
| Weight | Approx. 310 g |
| Mounting Type | DIN rail |
| Protection Rating | IP20 |
| Operating Temperature Range | 0°C to +60°C |
| Configuration Software | STEP 7 or TIA Portal |
| Status Indication | LED indicators for each channel |
FAQ
A1: Yes, every 6ES7322-1BH01-0AA0 we supply is 100% new, original, and factory-sealed from Siemens.Q2: What is the typical shipping time?
A2: We generally ship within 3 days to 2 weeks, depending on order size and selected logistics (DHL, FedEx, UPS).
Q3: What if the module shows a quality issue?
A3: We provide a 30-day return or replacement policy for any verified defects or performance problems.
Q4: Can this module switch AC loads?
A4: The 6ES7322-1BH01-0AA0 is optimized for 24V DC outputs; AC switching requires compatible interface relays.
Q5: Is it compatible with older S7-300 CPUs?
A5: Yes, the module is fully compatible across the SIMATIC S7-300 family and supports all standard CPU features.
