Overview
Specification
| Parameter | Specification |
|---|---|
| Part Number | 1C31125G03 |
| Module Type | Digital Output |
| Compatible System | Emerson Ovation DCS |
| Output Type | Digital discrete output, compatible with field devices |
| Output Signal Levels | Logic high/low voltage levels as per Ovation DCS standards |
| Output Channels | Single-channel or multi-channel configurations depending on rack setup |
| Response Time | Typically <5 ms per output, ensuring fast field control |
| Isolation | Electrically isolated from backplane to prevent interference |
| Power Requirements | Supplied via Ovation I/O backplane |
| Operating Temperature | -20 °C to +70 °C industrial ambient |
| Storage Temperature | -40 °C to +85 °C |
| Shock Resistance | 10 g half-sine wave, 11 ms |
| Vibration Resistance | 1 mm peak-to-peak 2–13.2 Hz; 0.7 g 13.2–150 Hz |
| Humidity | 5–95% non-condensing |
| Airborne Contaminants | ISA-S71.04 Class G3 |
| Hazardous Area Approvals | Optional, refer to DCS Center documentation |
| Mounting | Plug-in installation into Ovation I/O rack |
| Maintenance | No user-serviceable parts; supports quick replacement or repair |
| Diagnostic Features | Built-in status indicators for output health and operational diagnostics |
| Warranty | DCS Center warranty included |
| Compliance | Meets Ovation DCS hardware standards |
FAQ
A1: It provides reliable digital discrete output signals for controlling field devices.
Q2: Can this module operate in harsh industrial environments?
A2: Yes, it withstands industrial temperature ranges, vibration, and shock conditions.
Q3: How does the module integrate with Emerson Ovation DCS systems?
A3: It installs via plug-in design, ensuring seamless integration into Ovation I/O racks.
Q4: Does the module require calibration or maintenance?
A4: No calibration is required, and maintenance is minimal with quick replacement options.
Q5: What is the response time for output signals?
A5: The module typically provides output response times under 5 ms for fast control.
Q6: Is there a warranty for this module?
A6: Yes, all units come with a DCS Center warranty to guarantee reliable operation.
