Overview
Specification
| Attribute | Specification |
|---|---|
| Number of Modules per Controller | 1768-L43: 1 module1768-L45: 2 modules |
| Number of Axes per Module | 4 axes + 2 auxiliary feedback axes |
| SERCOS Data Rate | 4 Mbps / 8 Mbps |
| SERCOS Cycle Time @ 4 Mbps | 0.5 ms (up to 2 drives)1 ms (up to 4 drives)(Kinetix 6000 drives support 0.5 ms) |
| SERCOS Cycle Time @ 8 Mbps | 0.5 ms (up to 4 drives) |
| Drive Control Modes | Position or velocity |
| Current Draw @ 5.2V DC | 969 mA |
| Current Draw @ 24V DC | 0 mA |
| Power Dissipation | 5.04 W |
| Weight | 0.20 kg (7.11 oz) |
| Dimensions (HxWxD) | 132.015 × 56.68 × 105.1 mm (5.2 × 2.23 × 4.14 in) |
| Slot Width | 1 |
| Module Location | DIN rail or panel mount |
| Mounting Screw Torque | 1.16 N·m (10 lb·in), use M4 or #8 screws |
| Plastic Fiber-Optic Cables | 2090-SCEPxx-0 (non-jacketed, chlorinated polyethylene)2090-SCVPxx-0 (standard jacket, PVC)2090-SCNPxx-0 (nylon jacket) |
| Glass Fiber-Optic Cables | 2090-SCVGxx-0 (standard jacket, PVC) |
| North American Temperature Code | T4A |
| Enclosure Type Rating | None (open-style) |
FAQ
Yes, 1768-M04SE is 100% original Rockwell Automation, factory-sealed.How fast do you ship?
We have stock available and typically ship within 3 days to 2 weeks, depending on order size.
Which logistics companies do you use?
We commonly use DHL, FedEx, and UPS for safe and timely delivery.
What if there is a quality issue?
We support returns within 30 days.
How many axes does the module support?
1768-M04SE supports 4 Sercos axes for high-speed motion control.
Is it compatible with CompactLogix controllers?
Yes, it integrates seamlessly with the CompactLogix series.
