Overview
Specification
| Parameter | Specification / Description |
|---|---|
| Model Number | 1756-CFM |
| Module Type | Configurable Flowmeter |
| Compatible Platforms | Allen-Bradley ControlLogix, CompactLogix, and other PLC systems |
| Flow Medium | Liquids and gases |
| Flow Range | Configurable depending on application |
| Output Signals | Analog 4–20 mA, 0–10 V; Digital pulse or network data |
| Accuracy | ±0.5% of full-scale typical |
| Response Time | < 100 ms |
| Diagnostics | Continuous monitoring of flow signal integrity |
| Operating Temperature | 0°C to 60°C |
| Storage Temperature | -40°C to 85°C |
| Mounting | Panel or DIN-rail installation |
| Communication | Integrated with ControlLogix backplane or network modules |
| Dimensions | 140 × 120 × 60 mm |
| Weight | 1.2 kg |
| Certification | UL, CE, CSA |
FAQ
A1: It measures both liquids and gases, depending on the configured application.
Q2: How is the module integrated into an automation system?
A2: It connects directly to ControlLogix or CompactLogix PLCs via backplane or network modules.
Q3: Can the output be configured for analog and digital signals?
A3: Yes, the module supports 4–20 mA, 0–10 V analog outputs and digital pulse signals.
Q4: What is the typical accuracy of the flow measurement?
A4: Accuracy is typically ±0.5% of full scale under standard conditions.
Q5: Is the module suitable for harsh industrial environments?
A5: Yes, it features a robust design and complies with UL, CE, and CSA certifications.
Q6: How do engineers configure the flow ranges?
A6: Engineers can configure input and output ranges using Rockwell Automation software for each application.
