Overview
Specification
| Parameter | Specification |
|---|---|
| Module Type | 16-Point AC/DC Relay Output |
| Model | 1746-OW16 |
| Manufacturer | Rockwell Automation |
| Output Points | 16 |
| Output Type | AC/DC relay, SPST |
| Load Voltage | 5–125 V DC, 24–240 V AC |
| Load Current | 2 A per point |
| Response Time | ≤ 10 ms typical |
| Power Supply | 5 V DC and 24 V DC backplane power |
| Mounting | 1746 chassis mount |
| Dimensions | 120 mm × 35 mm × 115 mm |
| Weight | 0.4 kg |
| Operating Temperature | 0°C to +55°C |
| Certifications | UL, CE compliant |
| Energy Storage | Not required; relay retains state via backplane power |
FAQ
Yes, 1746-OW16 is 100% original Rockwell Automation, factory-sealed.
How fast is the shipping?
We have stock available and ship within 3 days to 2 weeks depending on order size.
Which logistics companies are used?
We commonly use DHL, FedEx, and UPS for safe and timely delivery.
What if there is a quality issue?
We support returns within 30 days for any quality-related issues.
How many output points does the 1746-OW16 provide?
The 1746-OW16 offers 16 independent AC/DC relay outputs.
What load voltage and current does it support?
It supports 5–125 V DC or 24–240 V AC loads with up to 2 A per point.
