Overview
Additionally, the 171CCC76010 adapter integrates seamlessly into the Modicon Quantum series, enhancing system flexibility and supporting efficient data exchange. Its compact and lightweight design simplifies installation without compromising reliability, making it suitable for a wide range of control applications.
Specification
| Category | Specification |
|---|---|
| Discrete I/O capacity | 8192 inputs / 8192 outputs |
| Register I/O capacity | 26048 inputs / 26048 outputs |
| I/O limit capacity | Maximum 8192 bits |
| I/O words/drop | 80 I/O (ProWORX), 128 I/O (Concept) |
| Program memory | 240 kB IEC, 18 kB LL984 |
| Data memory | 24 kB |
| Memory type | RAM 512 kB, Flash 512 kB |
| Word length | 16-bit |
| Rated supply voltage | 5.0 V DC ±5% |
| Power supply | By Momentum I/O base |
| Instruction speed | 1 ms per 1K instruction |
| Material | Lexan |
| Ports | 1 × RS232C non-isolated, 1 × I/O bus |
| Marking | CE |
| Weight | 0.042 kg |
| Protective treatment | TC |
| Operating temperature | 0…60 °C |
| Storage temperature | -40…85 °C |
| Relative humidity | 5…96% (non-condensing) |
| Operating altitude | Up to 2000 m |
| Shock resistance | ≤15 gn peak, 11 ms half sine wave |
| Vibration resistance | 0.75 mm d.a. / 1 gn |
| Certifications | CUL, FM Class 1 Division 2, NEMA Type 250, UL |
FAQ
Yes, all modules we supply are 100% new and original from Schneider Electric.
Q2: Do you keep the 171CCC76010 adapter in stock?
Yes, we maintain inventory, and shipping usually takes 3 days to 2 weeks, depending on order size.
Q3: How is the 171CCC76010 shipped?
We typically ship via DHL, FedEx, or UPS to ensure fast and secure delivery.
Q4: What is your return policy for the 171CCC76010 module?
We support returns within 30 days if any quality issues occur.
Q5: What are the main benefits of the 171CCC76010 adapter?
It delivers fast processing, reliable Modbus communication, easy integration with Modicon Quantum systems, and compact rack installation.
