Overview
Specification
| Specifications | |||||
| User Logic/Reference Capacity | 984 Ladder Logic | Discrete | Register | Extended Register | IEC Application Memory |
| 64k words | 64k | 57k | 96k | 2.7M | |
| 57,7664XX registers max Only if: 0XXX=16 and 1XXX=16 and 3XXX=16 | |||||
| Reference Capacity | |||||
| Discrete | 64k-any mix | ||||
| Local I/O) | |||||
| Maximum VO Words | 64 In and 64 Out* | ||||
| Maximum Number of I/O Racks | 2(Requires Expander) | ||||
| Remote I/O | |||||
| Maximum V/O Words per Drop | 64 In and 64 Out* | ||||
| Maximum Number of Remote Drops | 31 | ||||
| Distributed V/O | |||||
| Maximum Number of Networks per System | 3** | ||||
| Maximum Words per Network(for every DIO drop,there is a minimum of words input of overhead.) | 500 In and 500 Out | ||||
| Maximum Words per Node | 30 In and 32 Out | ||||
| ‘This information can be a mix ifDiscrete or Register I/O.For each word of register I/O configured,one word of I/O words must be subtracted from the total available.The same hokds true for each block of 8 bits or 16 bits of Discrete V/O configured—one word Register V 0 must be subtracted from the total available. “Requires the use of two 140NOM21×00 Option Modules. | |||||
| Maximun Number of Network Option Module Interfaces | Supports up to six network modules (i.e.,Modbus Plus, Ethemet and Mull-Axis Motion option modules)using the option module interface technique (see p.33). Note:Only two Modbus Plus modules can have full functionality,Including Quantum DIO support. | ||||
FAQ
A1: It supports Concept and ProWORX 32. Unity Pro can read but cannot fully edit programs.
Q2: Does this CPU support Ethernet networking?
A2: Yes. You can add Ethernet modules to enable Modbus TCP and networked I/O architectures.
Q3: Can it operate in high-temperature industrial areas?
A3: Yes. The CPU operates reliably from 0 to 60°C in properly ventilated enclosures.
Q4: How much memory is available for user applications?
A4: It provides 2,972 KB of RAM for logic, data storage, and communication handling.
Q5: Is the module suitable for system expansion?
A5: Yes. It supports large slot counts and works well with both local and remote I/O racks.
