Overview
In addition, the 1402-LS51/B module integrates seamlessly within PLC-5 architectures, allowing users to configure, monitor, and control synchronization parameters with exceptional flexibility. Therefore, it enhances operational efficiency and minimizes system downtime during phase transitions. Furthermore, its dependable performance and straightforward setup make it an excellent choice for manufacturers, integrators, and maintenance teams seeking reliable long-term system coordination.
Specification
| Parameter | Specification |
|---|---|
| Product Type | Line Synchronization Module |
| Series | PLC-5 Bulletin 1402 |
| Part Number | 1402-LS51/B |
| Function | Synchronizes AC line phases for PLC-controlled systems |
| Compatibility | PLC-5 controllers and related automation networks |
| Voltage Range | 85 to 264 VAC |
| Frequency Range | 47 to 63 Hz |
| Synchronization Accuracy | ±1° typical |
| Power Consumption | Approx. 10 VA |
| Indicators | Status LEDs for phase and synchronization monitoring |
| Mounting Type | Chassis-mounted |
| Operating Temperature | 0°C to +60°C (32°F to 140°F) |
| Storage Temperature | -40°C to +85°C (-40°F to 185°F) |
| Enclosure | Industrial-grade, corrosion-resistant housing |
| Certifications | UL, CE, CSA compliance |
| Dimensions | Approx. 260 mm x 100 mm x 60 mm |
| Weight | Around 1.5 kg |
FAQ
A1: It aligns the phase and frequency of PLC-controlled equipment with the main AC power line to ensure smooth synchronization and reliable system performance.
Q2: Is the module compatible with all PLC-5 controllers?
A2: Yes, the 1402-LS51/B is fully compatible with PLC-5 series controllers and supports integration with related Allen-Bradley hardware.
Q3: Can this module operate in high-temperature environments?
A3: Yes, it is designed to function reliably within an ambient temperature range of 0°C to +60°C.
Q4: What industries typically use this synchronization module?
A4: It is widely used in power generation, process control, heavy manufacturing, and automation systems requiring precise timing coordination.
