Overview
Specification
| Parameter | Specification |
|---|---|
| Model Number | 1400ELTC6/E |
| Manufacturer | Rockwell Automation / Allen-Bradley |
| Display Type | 10.4-inch color CRT or monochrome display (depending on configuration) |
| Input Method | Keypad terminal |
| Resolution | 640 x 480 pixels (VGA) |
| Memory Capacity | 4 MB application memory |
| Communication Ports | DH+, Remote I/O, RS-232, RS-485 |
| Power Supply | 100–240V AC, 50/60 Hz |
| Operating Temperature | 0°C to 50°C (32°F to 122°F) |
| Storage Temperature | -20°C to 70°C (-4°F to 158°F) |
| Mounting Type | Panel mount |
| Enclosure Rating | NEMA Type 12 / 13 (indoor use) |
| Certifications | CE, UL, and CSA compliant |
FAQ
A1: The terminal is compatible with Allen-Bradley PLC-5, SLC 500, and ControlLogix systems using DH+, RIO, or serial communication.Q2: Can I replace a damaged display without replacing the entire terminal?
A2: Yes. The display module can be serviced or replaced separately to extend product life.Q3: What software is used to program the 1400e series terminals?
A3: Configuration and programming are done using Rockwell’s PanelBuilder 1400e software.
Q4: Is the terminal suitable for harsh industrial environments?
A4: Yes. Its NEMA Type 12/13 enclosure rating provides protection against dust, oil, and non-corrosive materials.
