Overview
Hardware Specifications
| Parameter | Specification |
|---|---|
| Model | 00014647-00 |
| Brand | Bachmann electronic |
| Product Type | BACnet MS/TP Communication Interface Module |
| Communication Protocol | BACnet MS/TP |
| BACnet Object Capacity | Up to 128 BACnet objects |
| Supported Functions | Device discovery, object management, property access, alarm and event management, time synchronization |
| Configurable Baud Rates | 9600 bps, 38400 bps, 115200 bps |
| System Integration | Bachmann PLC and control systems |
| Network Integration | Third-party BACnet field devices |
| Installation | Bachmann rack configuration |
Industrial Control and BACnet Network Integration
The 00014647-00 interfaces BACnet MS/TP communication with Bachmann control hardware. The module supports up to 128 BACnet objects and provides access to object properties and device data.
Furthermore, the module supports configurable MS/TP transmission rates including 9600 bps, 38400 bps, and 115200 bps. Device discovery reduces manual network identification during commissioning, while BACnet alarm and event functions provide access to supported event information.
For PLC integration, the module provides a communication path between Bachmann control systems and compatible third-party BACnet field devices. The supplied data does not specify backplane bus throughput, electrical isolation ratings, connector pin assignments, or firmware compatibility limits; therefore, these parameters require verification against the applicable Bachmann hardware documentation.
Frequently Asked Questions
Q: Which communication protocol does the Bachmann 00014647-00 use?
A: The module uses BACnet MS/TP for communication with compatible BACnet devices.
Q: How many BACnet objects can the module support?
A: The supplied specification states a capacity of up to 128 BACnet objects.
Q: Which transmission rates are specified for the module?
A: The supplied data identifies configurable baud rates of 9600 bps, 38400 bps, and 115200 bps.
Field Installation Guidelines
- Install the module in the designated Bachmann rack or compatible system location.
- Confirm the module position and mechanical seating before energizing the control system.
- Connect the BACnet MS/TP network according to the approved system wiring documentation.
- Keep communication wiring separated from high-voltage and high-current power conductors where practical.
- Apply the specified network termination and shielding arrangement defined by the BACnet MS/TP installation design.
- Verify the configured baud rate against the connected BACnet MS/TP devices before commissioning.
- Confirm device discovery and BACnet object communication after network startup.
- Do not apply unspecified supply voltage, grounding, termination, or environmental limits without consulting the applicable Bachmann documentation
