Overview
In addition, the UR-1HH provides enhanced voltage regulation and short-circuit protection, maintaining operational integrity even under demanding industrial conditions. Therefore, it contributes to the overall reliability and longevity of substation automation systems.
Specification
| Parameter | Description |
|---|---|
| Model | UR-1HH |
| Manufacturer | GE Fanuc Multilin |
| Module Type | Power Supply Module |
| Compatible System | UR Series Universal Relays |
| Input Voltage | 100–240 VAC |
| Output Voltage | 24 VDC nominal |
| Output Current | 2.5 A maximum |
| Efficiency | >85% typical |
| Ripple & Noise | <100 mV peak-to-peak |
| Operating Temperature | -40°C to +70°C |
| Storage Temperature | -40°C to +85°C |
| Mounting | Plug-in module for UR chassis |
| Status Indicators | Power and fault LEDs |
| Protection | Overvoltage, overload, and short-circuit |
FAQ
Yes. It is fully compatible with UR Series relay modules.
Q2: Can the module be replaced without shutting down the system?
Yes. Hot-swappable design allows replacement during live operation.
Q3: What input voltage range does the module support?
It accepts 100–240 VAC input for flexible integration.
Q4: How does the UR-1HH protect downstream modules?
It includes overvoltage, overload, and short-circuit protection features.
Q5: What environmental conditions can it withstand?
The module operates reliably from -40°C to +70°C and tolerates industrial vibration.
