Overview
Unlike standard output modules, the T8461 uses a Triple Modular Redundancy (TMR) architecture to maintain uninterrupted operation even if one leg fails. This design ensures fault tolerance and high availability, making the module ideal for safety-critical control systems. Additionally, its compact form and intelligent diagnostics simplify installation and maintenance while improving overall system uptime.
Specification
| Parameter | Specification |
|---|---|
| Manufacturer | Rockwell Automation / ICS Triplex |
| Model | T8461 |
| Series | ICS Triplex |
| Module Type | Digital Output Module |
| Output Channels | 16 isolated channels |
| Output Voltage | 24 V DC nominal |
| Output Current | 0.5 A per channel (max) |
| Power Consumption | 5.5 W typical |
| Isolation | Channel-to-channel and channel-to-system isolation |
| Redundancy | Triple Modular Redundancy (TMR) |
| Scan Times | Simplex: 1.170 ms / Dual: 1.965 ms / Triple: 2.656 ms |
| Weight | Approx. 0.34 kg |
| Operating Temperature | –40 °C to +70 °C |
| Storage Temperature | –40 °C to +85 °C |
| Mounting | Standard Triplex I/O rack slot |
| Diagnostics | Continuous self-test and fault detection |
| Applications | Process control, safety, and critical automation systems |
FAQ
A1: Yes, every T8461 unit is 100% factory-sealed and original from Rockwell Automation.
Q2: How fast is delivery after order confirmation?
A2: We usually ship within 3 days to 2 weeks, depending on order volume and logistics.
Q3: What shipping carriers do you use?
A3: We ship worldwide using DHL, FedEx, UPS, and other trusted carriers.
Q4: Do you support returns if there’s a quality issue?
A4: Yes, we support returns within 30 days for verified quality issues.
Q5: Can the T8461 operate in redundant configurations?
A5: Absolutely. It supports simplex, dual, and triple configurations for maximum system reliability.
