Overview
Specification
| Parameter | Specification |
|---|---|
| Manufacturer | Rockwell Automation / ICS Triplex |
| Model | T8270 |
| Module Type | 24 V DC Fan Assembly |
| Fan Count | 4 units (Papst 8414NG) |
| Voltage Range | 18 to 28 Vdc |
| Power Consumption | 2 × 4 W |
| Airflow | 69 m³/h (40.6 ft³/min) |
| Noise Level | ~32 dB per fan |
| Fusing | Internal 250 mA anti-surge (per supply) |
| MTBF (individual fans) | 70,000 h at 40 °C; 35,000 h at 70 °C |
| Operating Temp | 0 °C to +60 °C |
| Non-operating Temp | –20 °C to +70 °C |
| Humidity | 10 % to 95 % non-condensing |
| Dimensions | 88 mm × 483 mm × 267 mm |
| Weight | Approx. 1.8 kg |
| Mounting | Rear rack-mounted in module chassis |
FAQ
A1: Yes, all T8270 units we supply are brand-new, factory-sealed, and genuine.
Q2: What is the typical shipping time?
A2: We ship within 3 days to 2 weeks, depending on stock and order volume.
Q3: What power setup does it require?
A3: It uses dual 24 Vdc supplies with internal anti-surge fusing for redundancy.
Q4: Can it protect itself against wiring faults?
A4: Yes, it includes reverse polarity protection and fused input protection.
Q5: What cooling performance does it deliver?
A5: At 3100 rpm, it moves ~69 m³/h of air with low noise (~32 dB per fan).
Q6: Where does this module mount?
A6: It mounts at the rear of a standard rack chassis for ICS Triplex module racks.
