Overview
Specification
| Specification | Details |
|---|---|
| Model | SPCIS22 |
| Manufacturer | ABB |
| System Compatibility | Bailey Infi 90 & Net 90 |
| Module Type | Control I/O Module (Analog Input) |
| Number of Channels | 4 independent analog input channels |
| Input Signal Range | ±10 V DC or 4–20 mA (selectable) |
| Input Resolution | 12-bit A/D conversion |
| Accuracy | ±0.1% of full scale |
| Input Impedance | >1 MΩ (voltage mode) / 250 Ω (current mode) |
| Sampling Rate | ≤10 ms per channel |
| Isolation Voltage | 500 V channel-to-ground and channel-to-channel |
| Power Supply Voltage | 24 V DC nominal |
| Power Consumption | ≤ 8 W |
| Operating Temperature | 0°C to +60°C |
| Storage Temperature | -40°C to +85°C |
| Dimensions (H × W × D) | 260 × 120 × 40 mm |
| Weight | Approx. 0.9 kg |
| Mounting Type | Plug-in module for rack installation |
FAQ
Q1: Is the ABB SPCIS22 module brand new and original?
Yes, every SPCIS22 module is 100% brand new, factory-sealed, and sourced directly from ABB.
Q2: What is the delivery time for SPCIS22 modules?
We ship within 3 days to 2 weeks, depending on order quantity and destination.
Q3: What shipping options are available?
We typically use DHL, FedEx, or UPS for fast and secure global delivery.
Q4: What should I do if there is a quality issue?
We offer a 30-day return policy for verified quality issues or defects.
Q5: What input signals can the SPCIS22 process?
The SPCIS22 supports both ±10 V DC and 4–20 mA input signals, making it suitable for various industrial sensors.
Manual/Datasheet PDF
SPCIS22 ABB Bailey Infi 90 & Net 90 Control IO Module 4 AI datasheet
