Overview
Specification
| Parameter | Specification |
|---|---|
| Brand | ABB |
| Model | PM5670-2ETH |
| Part Number | 1SAP151000R0378 |
| Product Type | Processor Module |
| CPU Type | 32-bit RISC processor |
| Program Memory | 4 MB |
| Data Memory | 2 MB |
| Retain Memory | 256 kB |
| Communication Ports | 2 × Ethernet, 1 × RS-485 |
| Supported Protocols | Modbus TCP, PROFINET, TCP/IP |
| Cycle Time | 0.01 ms per 1 k instruction |
| Integrated Web Server | Yes |
| Real-Time Clock | Yes |
| Operating Voltage | 24 V DC (±10%) |
| Power Consumption | Approx. 12 W |
| Operating Temperature | -25°C to +60°C |
| Storage Temperature | -40°C to +70°C |
| Mounting | DIN rail |
| Dimensions | 106 mm × 90 mm × 70 mm |
| Certifications | CE, UL, cUL, RoHS compliant |
FAQ
Q1: What are the main communication features of the PM5670-2ETH?
A1: It offers two Ethernet ports supporting Modbus TCP, PROFINET, and TCP/IP for fast data exchange and redundancy.
Q2: Is this module compatible with other AC500 series products?
A2: Yes, it integrates seamlessly with ABB AC500 I/O and communication modules for scalable control solutions.
Q3: Does it support remote access or monitoring?
A3: Absolutely. The integrated web server allows configuration, diagnostics, and monitoring over Ethernet.
Q4: How is it suited for harsh industrial environments?
A4: The module operates reliably in temperatures from -25°C to +60°C and meets industrial EMC standards.
Q5: Can it handle large automation tasks?
A5: Yes, with its enhanced memory and fast CPU, it efficiently manages large-scale control systems and data-heavy processes.
