Overview
The ABB IMDSM04 Pulse Input Slave Module is a precision-built unit designed for Bailey Infi-90 control systems. It handles frequency and pulse-based signals with exceptional accuracy, making it ideal for monitoring turbines, flow meters, and other critical industrial equipment.
With 8 independent channels, the IMDSM04 ensures reliable pulse acquisition without interference. Its compact size, rugged PCB construction, and stable connectors allow engineers to install it seamlessly into existing Bailey racks while maintaining long-term system stability.
Specification
| Parameter | Specification |
|---|---|
| Model Number | IMDSM04 |
| Manufacturer | ABB / Bailey Controls |
| Product Category | Pulse Input Slave Module |
| Compatible Systems | Bailey Infi-90 / Net 90 |
| Input Channels | 8 isolated pulse input channels |
| Supported Signal Types | Frequency, pulse, contact closure |
| Input Voltage Range | 5–48 V DC (depending on configuration) |
| Signal Frequency Range | 0.01 Hz to 10 kHz |
| Conversion Method | Digital pulse counting and frequency calculation |
| Dimensions | Approx. 300 mm × 250 mm × 40 mm (11.8 × 9.8 × 1.6 in) |
| Weight | ~1.7 kg (3.7 lb) |
| Mounting Method | Standard Infi-90 rack mount |
| Operating Temperature | 0°C to +60°C |
| Storage Temperature | –40°C to +85°C |
| Humidity Tolerance | 5%–95% non-condensing |
| Construction Material | Industrial-grade PCB with reinforced connectors |
FAQ
Q1: Is the ABB IMDSM04 module brand new and original?
A1: Yes, we only provide 100% new and factory-original IMDSM04 modules.
Q2: How quickly can you ship the IMDSM04 after purchase?
A2: We typically ship within 3 days to 2 weeks, depending on order size and logistics.
Q3: Which shipping methods are available for delivery?
A3: We commonly use DHL, UPS, and FedEx for reliable global shipping.
Q4: How many channels does the IMDSM04 support?
A4: The module includes 8 isolated pulse input channels for versatile applications.
Q5: What is your warranty or return policy for the IMDSM04?
A5: If any quality issue occurs, you may return the product within 30 days.
