Overview
Specification
| Parameter | Specification |
|---|---|
| Brand | ABB |
| Model | PM5650-2ETH |
| Part Number | 1SAP141000R0278 |
| Product Type | Processor Module |
| CPU Type | 32-bit RISC processor |
| Program Memory | 2 MB |
| Data Memory | 1 MB |
| Retain Memory | 128 kB |
| Communication Ports | 2 × Ethernet, 1 × RS-485 |
| Ethernet Protocols | Modbus TCP, PROFINET, TCP/IP |
| Cycle Time | 0.015 ms per 1 k instruction |
| Real-Time Clock | Integrated |
| Operating Voltage | 24 V DC (±10%) |
| Power Consumption | Approx. 10 W |
| Operating Temperature | -25°C to +60°C |
| Storage Temperature | -40°C to +70°C |
| Mounting | DIN rail |
| Dimensions | 106 mm × 90 mm × 70 mm |
| Certifications | CE, UL, cUL, RoHS compliant |
FAQ
Q1: What communication options does the PM5630-2ETH support?
A1: It supports Modbus TCP, PROFINET, and standard TCP/IP via dual Ethernet ports.
Q2: Can it be used with other ABB AC500 series modules?
A2: Yes, it is fully compatible with the AC500 PLC platform and I/O modules.
Q3: Does it include a real-time clock for time-based operations?
A3: Yes, the PM5630-2ETH features an integrated RTC for scheduling and logging.
Q4: What is the recommended operating temperature range?
A4: It operates reliably from -25°C to +60°C, suitable for industrial conditions.
Q5: How is data protected during power outages?
A5: The module uses non-volatile memory to retain critical data during power loss.
