Overview
Specification
| Parameter | Specification |
|---|---|
| Model | EGB‑13P |
| Product Type | Proportional Electro-Hydraulic Governor/Actuator |
| Input Signal | 20–160 mA Proportional |
| Maximum Work Capacity | ~14.2 J (10.5 ft‑lb) |
| Useful Work Capacity | ~9.5 J (7 ft‑lb) |
| Stalled Torque Rating | ~19 N·m (14 lb‑ft) |
| Operating Pressure (Oil Pump) | ~896 kPa (130 psi) |
| Construction | Cast iron base & housing, cast-aluminum column |
| Mounting Orientation | Vertical |
| Operating Temperature Range | −40 °C to +85 °C |
| Weight | ~45–52 kg depending on options |
| Mechanical Backup | Ballhead governor for signal failure |
| External Adjustments | Droop and load-limit settings |
| System Compatibility | Woodward NetCon Control Architecture |
FAQ
A1: If the proportional electronic signal fails, the mechanical ballhead governor automatically takes over. This allows either a controlled shutdown or continued speed regulation, ensuring safe operation.
Q2: What types of engines or turbines can the EGB‑13P work with?
A2: The EGB‑13P supports dual-fuel, diesel, and gasoline engines, as well as gas or steam turbines, providing precise actuator control across multiple industrial applications.
Q3: Does the EGB‑13P require external hydraulic oil?
A3: No, it has a self-contained hydraulic oil supply, which reduces plumbing complexity and simplifies maintenance procedures.
Q4: Can I adjust droop or maximum fuel limit?
A4: Yes, external droop and load-limit adjustments allow fine-tuning for load sharing and maximum fuel demand, giving engineers flexibility in system integration.
Q5: How should the EGB‑13P be mounted?
A5: It is designed for vertical mounting to ensure proper operation and hydraulic flow, as recommended in Woodward installation guidelines.
