Overview
The ABB DO810 3BSE008510R1 module serves as a digital output (DO) module in ABB’s Advant DCS and 800xA systems. It delivers 16 output channels at 24V DC, grouped into two isolated sets of 8 channels. It includes protection against short circuits, over-voltage, and overheating, ensuring safe and reliable performance for industrial automation.
Specification
| Category | Specification |
|---|---|
| Manufacturer | ABB (ASEA Brown Boveri) |
| Model / Part Number | DO810 3BSE008510R1 |
| Exchange Number | EXC3BSE008510R1 |
| Product Type | I/O Module |
| Medium Description | Digital Output 24 V DC, 2×8 channels, 0.5A per channel, short-circuit proof, 50V isolation |
| Compatible Termination Units | TU810, TU812, TU814, TU830 |
| Number of Channels | 16 (Digital Output) |
| Input Channels | N/A |
| Output Channels | 16 |
| Output Rating | 24 V DC, 0.5 A per channel |
| Protection | Short-circuit proof, group isolation 50V |
| Compliance | RoHS (EU Directive 2011/65/EU) |
| WEEE Category | 5. Small Equipment (no external dimension >50 cm) |
| Number of Batteries | 0 |
| Dimensions (L × H × W) | 150 mm × 150 mm × 75 mm |
| Weight | 0.26 kg (~0.57 lbs) |
| Country of Origin | China (CN), India (IN) |
| Customs Tariff Number | 85389091 |
