Overview
The DO802 3BSE022364R1 is an 8-channel digital output relay module specifically designed for the ABB DCS/800xA system. It delivers fast, reliable switching for industrial automation applications, enabling precise control while seamlessly integrating with S800 I/O modules. Each channel provides galvanic isolation, which prevents interference and ensures stable system operation. Additionally, the module supports non-redundant configurations and features an on-board diagnostics interface for real-time operational monitoring.
Thanks to its compact and lightweight design, the DO802 installs easily on a standard DIN rail, while maintaining robust connectivity. Moreover, it offers high insulation and a durable construction, which guarantees reliable performance even in demanding industrial environments. Overall, this module is ideal for applications that require accurate relay outputs and consistent, dependable operation across multiple channels.
Specification
| Specification | Details |
|---|---|
| Product ID | 3BSE022364R1 |
| ABB Type Designation | DO802 |
| Catalog Description | Digital Output Relay, 8 Channels |
| Long Description | 24–230 V AC/DC, individually galvanic isolated channels |
| Product Type | I-O Module |
| Channel Type | DO |
| Number of Output Channels | 8 |
| Dimensions (Depth × Height × Width) | 58.5 × 102 × 86.1 mm |
| Net Weight | 0.24 kg |
| RoHS Status | Following EU Directive 2011/65/EU |
| WEEE Category | 5. Small Equipment (No External Dimension More Than 50 cm) |
| Number of Batteries | 0 |
| HS Code | 853890 |
| Customs Tariff Number | 85389099 |
| Country of Origin | Sweden (SE) |
| SCIP | 78452c78-19cc-4ae6-b677-9892ca797e6d |
