Overview
Specification
| Parameter | Details |
|---|---|
| Model Number | ATK4A‑00 |
| Product Type | 16‑Channel KS Cable Interface Adapter |
| Number of Channels | 16 (with optional 8‑point configuration) |
| Signal Types Supported | 4–20 mA DC or 1–5 V DC analog signals |
| Input Resistance | Approx. 400 Ω @ 20 mA; up to 1000 Ω @ 4 mA |
| Accuracy | ±16 μA (for 4–20 mA) and ±4 mV (for 1–5 V) |
| Data Update Period | ~10 ms typical |
| Transmitter Power Supply | ≥14.8 V @ 20 mA and ≤26.4 V @ 0 mA |
| Maximum Current Consumption | 310 mA (5 V DC), 450 mA (24 V DC) |
| Connecting Cable Types | KS1 or KS2 communication cables |
| Protection / Enclosure Rating | IP54 industrial-grade protection |
| Operating Temperature | ‑20°C to +70°C (‑4°F to 158°F) |
| Storage Temperature | ‑40°C to +70°C (‑40°F to 158°F) |
| Dimensions (Approx.) | W100 × H67 × D50 mm (3.94 × 2.64 × 1.97 in) |
| Weight (Approx.) | 0.1–0.2 kg depending on configuration |
| Mounting | Panel or rack installation for DCS signal interfacing |
| Applicable Systems | Yokogawa CENTUM VP / CENTUM CS Distributed Control Systems |
| Typical Applications | Interface field transmitters to KS bus and I/O modules in industrial DCS |
FAQ
A1: It provides 16 channels for KS module connections in industrial control systems.
Q2: Is it compatible with Yokogawa controllers?
A2: Yes, it integrates seamlessly with Yokogawa KS modules and controllers.
Q3: Can it operate in harsh industrial environments?
A3: Yes, it functions reliably from 0°C to 55°C and tolerates storage up to 70°C.
Q4: How does it simplify system installation?
A4: Its modular design reduces wiring complexity and facilitates straightforward panel mounting.
Q5: What maintenance is required?
A5: Minimal maintenance is needed; periodic inspection of connectors ensures consistent performance.
Q6: Does the adapter meet international safety standards?
A6: Yes, it is CE certified and meets relevant industrial safety and performance standards.
